Currie 36 Volt 6-Pin Controller (600, 750, & 1000 Series Schwinn, GT, IZIP, eZip, & Mongoose Scooters)

Factory OEM electric scooter controller from Currie Technologies.

The 36 Volt 25-30 Amp diagnostic voltage controller is an exclusive Currie Technologies design, with Currie's PWM Smart Power Microprocessor. The controller is fully water- proof, with brake inhibit power cut off.

Controller comes with four connectors for easy installation. Note that the flat black connector contains six pins within the connector (connected by six wires). Not compatible with 3-pin or 5-pin versions.

Connectors:
1. White connector with two wires - blue and green.
2. Black connector with two wires - black and red.
3. White connector with two wires - black and red.
4. Black connector with six wires - red, yellow, green, blue, black, and purple.

Input Voltage: 36V
Control Voltage: 1-4V
Output Current: 25-30A(M)

Known Compatibility (6-Pin Connector Versions):

• eZip 1000 Electric Scooter
• GT GT750 Electric Scooter
• IZIP I600 Electric Scooter
• IZIP I750 Electric Scooter
• IZIP I1000 Electric Scooter
• Mongoose M750 Electric Scooter
• Schwinn S600 Electric Scooter
• Schwinn S750 Electric Scooter
• Schwinn S1000 Stealth Electric Scooter

NOTE: The controller received will be either 25A or 30A output. Both 36 Volt 6-Pin controllers with the connectors pictured are interchangeable.
